ACS750LCA-050

current sensor ICs, Single +5 V supply, 13 kHz bandwidth

Rated 5 Rating 5 | reviews | Write a review

Price:: US $4.20~4.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $4.20~4.50

PartNumber:: ACS750LCA-050

Brand:: Allegro MicroSystems - Allegro | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Sunny Chen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-05-04

From Other Seller

Part Number:ACS750LCA-050
US $4.20 - 4.50
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
FM31256-G

US $2.40 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ACS750LCA-050 family of current sensor ICs provides economical and precise solutions for current sensing in industrial, automotive, commercial, and communications systems. The device package allows for easy implementation by the customer. Typical applications include motor control, load detection and management, power supplies, and overcurrent fault protection.

Parametrics

Absolute maximum ratings: (1)Supply Voltage: 16 V; (2)Reverse Supply Voltage: –16 V; (3)Output Voltage:16 V; (4)Reverse Output Voltage: –0.1 V; (5)Maximum Basic Isolation Voltage: 353 VAC, 500 VDC, or Vpk V; (6)Maximum Rated Input Current: 100 A; (7)Output Current Source: 3 mA; (8)Output Current Sink: 10 mA; (9)Nominal Operating Ambient Temperature: Range L –40 to 150 ℃, Range S –20 to 85 ℃; (10)Maximum Junction: 165 ℃; (11)Storage Temperature: –65 to 170 ℃.

Features

Features: (1)Monolithic Hall IC for high reliability; (2)Single +5 V supply; (3)3 kVRMS isolation voltage between terminals 4/5 and pins 1/2/3 for up to 1 minute; (4)13 kHz bandwidth; (5)Automotive temperature range; (6)End-of-line factory-trimmed for gain and offset; (7)Ultra-low power loss: 130 μΩ internal conductor resistance; (8)Ratiometric output from supply voltage; (9)Extremely stable output offset voltage; (10)Small package size, with easy mounting capability; (11)Output proportional to AC and DC currents.
